Shoto 5.12kWh Lithium-Ion Battery – 5000+ Cycles, Rack Mount

Description:

The Shoto 5.12kWh Lithium-Ion Battery is a high-performance energy storage solution, engineered for residential and commercial solar applications. With over 5000 cycles at 90% Depth of Discharge (DOD) and a 10+ year design life, this battery ensures long-term reliability and efficiency. The rack-mounted structure allows for easy installation, while its scalable parallel capability of up to 16 units makes it ideal for expanding energy storage needs.

Key Features:

High-Capacity Energy Storage
- 5.12kWh nominal capacity with 4.6kWh usable energy for optimized performance.
- 90% DOD extends battery lifespan and increases efficiency.
Reliable & Long-Lasting Design
- More than 5000 cycles at 25°C for durable, long-term use.
- 10+ year design life for sustainable energy storage.
- Wide operating voltage range (42V – 57.6V) to support various load requirements.
Flexible Installation & Scalability
- Rack mounted design for space-saving installation.
- Parallel up to 16 units to increase storage capacity as needed.
Advanced Battery Management System (BMS)
- Intelligent charge and discharge management to prevent overcharging and deep discharge.
- Boost & float charge control (57.6V / 54V) to maintain battery health.
Durable Construction for Various Environments
- Operating humidity: 5% – 95%
- Altitude tolerance: ≤4000m
- Reliable terminal stud (M8) for secure connections

Technical Specifications:

Model: (SDC10-Box 5)
Nominal Capacity: 5.12kWh
Rated Capacity: 100Ah
Operating Voltage Range: 42V – 57.6V
Charge Voltage: 57.6V
Discharge Voltage: 48V
Nominal Voltage: 51.2V
Maximum Parallel Units: 16
Cycle Life: ≥5000 cycles
Installation Type: Rack Mount / Wall Mount
Terminal Stud: M8
Humidity Tolerance: 5% – 95%
Altitude Limit: ≤4000m

Compatible Inverters:

Growatt, Goodwe, Victron, Deye, Sofar, LuxPower, and more.

What’s Included:

-1 × Shoto 5.12kWh Lithium-Ion Battery (SDC10-Box 5)
-Battery Cables

Warranty & Installation Requirements:

5-Year Warranty
All inverters and batteries must be installed by a qualified electrical wireman or Master electrician with a valid registration with the Department of Labour. A valid electrical certificate of compliance (COC) must be issued once installed, specific to the installation of the backup or solar system. Any warranty claim submitted without installation photos, a valid COC, and proof of a qualified wireman/master electrician installing the unit, can be rejected and will render the warranty claim null at the void.
